UHZ-221 Magnetic level gauge

UHZ-221 Top-mounted magnetic level gauge

Overview

The UHZ-221 Top-mounted magnetic level gauge (no protection tube top mounted type)is ordinary type top mounted magnetic level indicator can be used to indicate the level of various kinds of underground tank, pond, vessel, and the vessel which is not suit to open holes on the side, The main body material of level indicator is stainless steel . As the measuring indicator is totally isolating with the measured medium, so this kind of level indicator feature the advantage of clear indication, easy observation, safe and sound.

With the advantage of clear indicator, easy observation, there are three kinds of field indication for selection , which are red/white flap roller or flap ball，and floating buoy.

Main tech data

UHZ-221 Top-mounted magnetic level gauge (no protection tube top mounted type)

Measuring range: 0~600mm- 4000mm
Measuring accuracy: ± 10mm
(Reversingcolunm diameter 10mm)
Operating pressure:- 0.1MPa~4Mpa
Operating temperature: -15~ 420C°

Medium density: ≥0.5g/cm³

Medium viscidity: ≤0. 02Pa.S
(Normal temperature.)
Connection flange standard: HG20592~ 20635- 97。
(GB、JB、JIS、ANSI) Other standard on request
Connection spec: DN150; PN 1.0. 1.6. 2.5.4.0

Flange spec made by customer demand, but flange diameter not less than DN100
Contact material: stainless steel 304 (316L)

Note: Any special design or question of UHZ-221 Top-mounted magnetic level gauge (no protection tube top mounted type)，kindly contact the manufacturer for more details.
